This is a burning technology on the recording surface consisting of moving and fixed recording leaves placed in a ladder shape and creating a tilted recording. Under the effect of the movement of the moving recording leaves, the fuel layer is disturbed and moves on the recording. The recording leaves are continuously moved by a mechanism driven by an electric motor or hydraulic cylinder. In a ladder fire chamber, the combustion stages of the combustion process occur in each zone. Air supply for the combustion process will be adjusted for each zone to satisfy the combustion stages. The ladder burner is suitable for fuels with a lot of volatile matter, and can burn fuels with a lot of ash and high humidity.
Design standards | : According to ASME and TCVN standards |
Manufacturing standards | : According to ASME and TCVN standards |
Steam generation capacity | : 5,000 - 300,000 Kg/hour |
Design pressure | : 10 - 150 bar |
Steam parameters | : Steam saturated or superheated steam |
Boiler efficiency | : 85 ± 2 % |
Fuel | : Industrial waste products, tree bark,... |
